Fire Rated

Kawneer's complete range of Fire Resistant solutions enables design flexibility when fire protection is a requirement to building design.

Kawneer's product solutions enable safe evacuation of building occupants by offering fire and smoke protection in escape routes. They can also be used to prevent the spread of fire through the building and to adjacent buildings. The performance of this system is heavily dependent on the performance of the individual profiles, hardware items, specialist glazing and the interface between the system and the building structure. All these factors have been carefully considered in the development of this product.

The AA®720 FR consists of door and fixed light variants that are compliant with the latest European standards offering 30 minute insulation and integrity.

This is cleverly achieved using additional components to the standard AA®720 System and with the use of specialist fire-rated glazing.

Product Features:

Same versatility as the AA®720 Series
Extensive panic hardware offer
Wide range of hardware options
Specialist cooling material within the profiles
Intumescent strip
Specialist steel glazing clips and retaining bolts
Suites with AA®100/AA®110 FR Curtain Walling
Tested and certified in accordance with DIN EN 1634-1 and DIN EN 1634-3 at various locations
Similar UFrame values as the standard AA®720 Door and Fixed Light variants
Aesthetics

With the decisive advantage of...
Inward and outward opening single and double doors, combined with integrated fixed lights
Integrated panic doors
Large range of options and configurations for Architects and Specifiers
Helps keep the aluminium at a temperature under the melting point
Protection against smoke and heat penetration
Maintaining the structural integrity of the system
Total design flexibility. Offering total project solutions
Offering protection against both fire and smoke
Complies with all current thermal regulations
Profile depths and widths are the same as the standard AA®720 System

Performance

Kawneer's AA®720 FR has been tested in accordance with DIN EN 1634-1 achieving El230 (insulation and integrity), and has met the requirements of DIN EN 1634-3 for smoke protection. Testing has been carried out at various locations.

It has also been tested to:
Air Infiltration BS EN 12207: 2000 (Class C2)
Watertightness BS EN 12208: 2000 (Class 4A)
Wind Resistance BS EN 12210: 2000 (Class 2)

Glass
The AA®720 FR has been tested with specialist glazing. All glazing options are available in the AA®720 FR Product Manual.
