SD/SFG Ground Floor Systems

The SD/SFG system has been designed to provide a high performance commercial door and framing solution capable of being manufactured in single, double, and emergency door types and utilising low thresholds and a variety of options such as radius anti-finger trap stiles. It is capable of accepting glazing from 6mm to 24mm thick depending on weight. The aluminium SD Door is capable of being manufactured in single, double and emergency door types. It utilises low thresholds and a variety of options such as radius anti-finger trap stiles.

Materials

  • All aluminium sections are extruded using Aluminium Alloy 6060 or 6063 T6 to BS EN 755 part 9 2008.
  • Gaskets are manufactured in accordance with BS3734.

Finishes
SD/SFG framing sections are available typically in 3 finishes.

  • Polyester Powder Coating to BS EN 12206: 2004 Part 1 painted in house at 40 microns standard, or enhanced to 60 microns for marine environments, in accordance with ISO 9001, ISO 14001 and ISO 18001.
  • Anodised and Anolok finishes are to BS3897: 1991 to a minimum of 25 microns (AA25), supplied in either satin or polished finish in a limited range of colours.
  • Mill finish.

Construction
SD/SFG is constructed with square cut components, mechanically jointed using self tapping screws into special cleats, and torsion bars are used for compressive strength. A proprietary sealant is used on all metal joints in line with good practice. Automation solutions are also available.
